Popular Design for Color Doppler Lower Limb - CE echo machine phased array probe trolley color Doppler ultrasound – Sunbright
Popular Design for Color Doppler Lower Limb - CE echo machine phased array probe trolley color Doppler ultrasound– Sunbright Detail:
| Place of Origin | Shanghai, China |
| Brand Name | Sunbright |
| Model Number | SUN-908B |
| Instrument classification | Class II |
| Type | Portable Ultrasonic Diagnostic Devices, color Doppler |
| imaging mode | 2D, 3D, CF+B model simultaneously, PDI, DPDI, TDI, TSI,etc |
| User rights control | YES |
| Probe connectors | 4 |
| PW duplex and triplex switched freely | YES |
| IMT auto measuremet | YES |
| CW function | YES |
| Complex model Image | YES |
| PW auto trace measurements | YES |
| software package | General, OB/GYN. small parts Urology |
Supply Ability
Supply Ability:20000 Unit/Units per Year Color Doppler
Packaging & Delivery
Packaging Details: Sea-worthy packing/Air-worthy packing for Color Doppler
Port: Shenzhen/Shanghai
Lead Time
| Quantity(Units) | 1 – 5 | >5 |
| Est. Time(days) | 3 | To be negotiated |
Product Description
CE echo machine phased array probe trolley color Doppler ultrasound.
Application: Abdomen / Cardiac / Obstetrics / Gynecology / Urology / Andrology / Small Parts / Vascular / Pediatrics / Musculoskeletal and so on
Scanning images
3d portable ultrasound scanner/3d doppler ultrasound/doppler ultrasound machines price
Physical Specifications
| Equipment weight | 80kg |
| Packing size | 100cm×80.5cm×148cm |
| Packing weight | 200kg |
Connectivity/Media/Peripherals
| Transducer Ports | 4 |
| USB Ports | 4 |
| Hard Disc | 64GB (SSD), 120G/200GB SSD (Optional) |
| Printing Area | Image, report, Image+report |
| Ethernet Port | 2(100Mb/1000Mb) |
| External Display | VGA, HDMI, |
| Printer(Optional) | USB Printer, Digital Laser Printer, Digital B/W Thermal Printer |
Hardware Specification
LED Monitor
| Size (Diagonal) | 15″ |
| Contrast Ratio | 800:1 |
| Resolution | 1024*768 pixels |
| Brightness | 230 cd/m2 |
| Color Depth | 24bit |
| Rotate Angle | ± 90° |
| Grey Levels | 256 |
Cine/Image Memory
| Cine Memory | 1200 frame (max) |
| Cine Review Speed | 1, 2, 4, 8 |
| Cine Review Loop | YES |
| Cine Capture Function | YES |
DICOM Connectivity
DICOM3.0 Compliant
4D Software
Built-in 4D software
Image Storage
Storage Format: PNG, AVI, BMP, JPEG, DICOM
Export Video Format: AVI
Export Image Format: PNG, JPEG, BMP, DICOM
USB Flash Drive
| Digital technology | Panoramic Imaging Tech All-digital signal processing Tech Multi-beam formation Tech Speckle Reduction Tech Tissue Harmonic Imaging Tech Dynamic Tissue Optimization Tech Duplex & Triplex Synchronous Display Directional Power Doppler Imaging Parameters Preset Tissue Special Image PW Auto Trace Update in line CF+B mode in one screen Complex Model Imaging IMT auto measurements Virtual convex array Trapezoidal imaging | ||
| General Performance: | Digital Broadband | 12288 channels |
| Beam-former | Re-programmable | |
| Transmit Voltage | Adjustable (15 steps) | |
| Beam-former Frequency Range | 1~40 MHz |
Pan/Zoom
Real-Time Image Zoom, Zoom Range: 100%~400%, Up/Down/Left/Right Inversion
Transducers
| Probe | Convex Array Probe | Linear Array Probe | Intra-Cavity Probe | Micro-convex probe |
| Frequency | Central 3.5 MHz(2.0MHZ to 10.0MHZ) | Central 7.5 MHz(2.0MHZ to 10.0MHZ) | Central 6.5 MHz(2.0MHZ to 10.0MHZ) | Central 4.0 MHz(2.0MHZ to 10.0MHZ) |
| Pitch | 0.516mm | 0.352mm | 0.216 mm | |
| Radius | 60mm | N/A | 10 mm | |
| Elements | 128 | 128 | 128 |
User Interface
User Permission setting.
Intuitive Windows-based operating principles.
User-centric control panel with Home Base layout and control customization.
On/Off task light and back-lit illumination of control panel.
Variable brightness indicates active state of function keys.
Easily accessible, full size QWERTY keyboard for text entry, function keys and system programming.
Cine Playback, Multiple Arrows, Configurable Worksheets, Exam Review, Pictograms (Body Marks),System Setup Menu.
On line attention function, tell the user how to operate in the next step.
Standard
906B color Doppler main unit
15″LCD with high resolution
4D software
CW function
Two USB ports
Two probe connectors
One s-video out port
One video port
One power inlet
One convex probe(3.2M R50)
One transducer connector
One VGA video converter
Plenty of measurement & calculation software packages
24 months warranty since ex-factory date for main unit
12 months warranty since ex-factory date for probes
